ENGENIUS OUTDOOR WIRELESS-N ACCESS POINT

From the Manufacturer Expand your business network beyond the walls of your building so employees and guests can access it and your Internet connection when they're outside. The EnGenius ENS202EXT is a high-powered, long-range 2.4 GHz Wireless N300 Outdoor Access Point delivering data rates up to 300Mbps and is ideal for providing connectivity to a small business network and its Internet connection for restaurant patrons, or for students and employees in educational or corporate campus venues. ENS202EXT is compliant with the IEEE802.11b/g/n standards delivering a wireless data rate of up to 300Mbps on the 2.4 GHz frequency spectrum. It features two omni-directional 5 dBi MIMO (Multiple In/Multiple Out) antennas that coupled with its strong transmit power of up to 400mW make it a compelling performance solution for small and growing businesses at a very affordable price. ENS202EXT also features a robust security feature set that includes support for WPA/WPA2 Personal and Enterprise encryption, 802.1x RADIUS authentication, hidden SSID and MAC address filtering. ENS202EXT has an IP65 rated weatherproof housing that ensures continued operation in harsh outdoor environments or in climates of extreme cold, heat or continuous moisture. Product Features 400mW high transmit power enabling long range connectivity Designed for outdoor deployment with IP65 waterproof housing Supports IEEE802.11b/g/n wireless standards with up to 300 Mbps data rate Two detachable 5 dBi omni-directional MIMO antennas Signal strength LED indicators, pole mount kit, PoE kit provide easy installation Can be monitored after deployment with EnGenius EZ Controller™ software for Windows ENS200 ENS200EXT ENS202 ENS202EXT ENS500 ENS500EXT Wi-Fi Standard Wireless N Wireless N 802.11 b/g/n 802.11 b/g/n 802.11 a/n 802.11 a/n Frequency Band 2.4Ghz 2.4Ghz 2.4Ghz 2.4Ghz 5Ghz 5Ghz Maximum speed Up to 150Mbps Up to 150Mbps Up to 300Mbps Up to 300Mbps Up to 300Mbps Up to 300Mbps RF Power in dBm 26dBm 26dBm 26dBm 26dBm 26dBm 26dBm RF Power in mW 400mW 400mW 400mW 400mW 400mW 400mW Access Point Mode ✔ ✔ ✔ ✔ ✔ ✔ Client Bridge ✔ ✔ ✔ ✔ ✔ ✔ WDS Bridge ✔ ✔ ✔ ✔ ✔ ✔ WDS AP ✔ ✔ ✔ ✔ ✔ ✔ WDS Station ✔ ✔ ✔ ✔ ✔ ✔ Client Router ✔ ✔ ✔ ✔ ✔ ✔ LAN Interface 10/100 x 2 10/100 x 2 10/100 x 2 10/100 x 2 10/100 x 2 10/100 x 2 Antenna 1x Built-in 8dBi Directional 1x External 5dBi Omni Directional 2x Built-in 8dBi Directional 2x5 dBi External Omni Directional 2x Built-in 10dBi Directional 2x External10 dBi Omni Directional Antenna connector Type NA SMA NA SMA NA SMA Encryption WEP/WPA/WPA2 WEP/WPA/WPA2 WEP/WPA/WPA2 WEP/WPA/WPA2 WEP/WPA/WPA2 WEP/WPA/WPA2 SSID Broadcast Disabled Security ✔ ✔ ✔ ✔ ✔ ✔ Multiple SSID ✔ ✔ ✔ ✔ ✔ ✔ SSID to VLAN Mapping ✔ ✔ ✔ ✔ ✔ ✔ Client Isolation ✔ ✔ ✔ ✔ ✔ ✔ Radius client support ✔ ✔ ✔ ✔ ✔ ✔ VPN Pass-through support ✔ ✔ ✔ ✔ ✔ ✔ 802.1X ✔ ✔ ✔ ✔ ✔ ✔ MAC address Filtering ✔ ✔ ✔ ✔ ✔ ✔ QoS Support ✔ ✔ ✔ ✔ ✔ ✔ Telnet SNMP ✔ ✔ ✔ ✔ ✔ ✔ Management Software / Controller ✔ ✔ ✔ ✔ ✔ ✔ PoE power 24v 24v 24v 24v 24v 24v PoE kit ✔ ✔ ✔ ✔ ✔ ✔ IP rating 65 65 65 65 65 65 Certification FCC FCC FCC FCC FCC FCC Primary application CPE for high-speed wireless Internet access point 2 multipoints building to building building to building building to building building to building Secondary application Extend home network beyond the wall 2.4Ghz N150 radio bridge high-speed CPE device 2.4Ghz N300 radio bridge high speed mid-long range P2P network 5GHz single radio bridge Specialty application Outdoor video IP cam wireless client Outdoor IP Cam AP Outdoor video IP cam wireless client Small base station replacement Outdoor IP cam AP in congested 2.4GHz area Highly interferred 2.4GHz wireless traffic Product Description "The EnGenius ENS202EXT is a high-powered, long-range 2.4 GHz Wireless N300 Outdoor Access Point delivering data rates up to 300Mbps and is ideal for providing connectivity to a small business network and its Internet connection for restaurant patrons, or for students and employees in

FEATURES

• 802.11n Speeds up to 300Mbps on 2.4 GHz
• Weatherproof IP55-Rated Housing Resists Harsh Climates
• Robust 26dBm Transmit Power Supports Wireless to Yards & Patios
• 2 Detachable 5dBi, MIMO Antennas Maximize 360 Degree Coverage
• PoE Extends Power to Unwired Areas; Connect Remote IP Cameras or APs via 2nd Port
• High 400mW power delivers long-range coverage
• Up to 300 Mbps when connected with other Wireless N devices
• Two 5 dBi Omni-directional antennas
